IDEAL Barrier Strips 12-Circuit, 35A/300V, 22-10AWG, Model 89-612*
Description
IDEAL Barrier Strips are designed and manufactured to be rugged, reliable, and easy to use. A thermoplastic base and corrosion-resistant screws and hardware provide extended service life.
Features
- Modular 12-circuit design can be cut into sections or stacked end to end
- Recessed screws and tubular contacts provide added safety and help prevent short circuits
- Tubular contacts connect stripped, un-terminated solid or stranded wire directly to each contact
- Integrated wire protectors prevent twisting and breakage of stranded wire during connection
- Rugged nylon construction rated to UL 94V2
- Ratings: Wire Range 22 - 10 AWG, 35A/300V UL Listed, CSA Certified.
Technical Information
Number of Poles: 12-Pole
Quantity: Individual
Length: 1,000'
Maximum Operating Temperature: 105°C
Maximum Rated Voltage: 300V
Maximum Wire Gauge: 10 AWG
Minimum Wire Gauge: 22 AWG
Torque (in / lb): 7
Document
Original: $11.67
-65%$11.67
$4.08
Description
Description
IDEAL Barrier Strips are designed and manufactured to be rugged, reliable, and easy to use. A thermoplastic base and corrosion-resistant screws and hardware provide extended service life.
Features
- Modular 12-circuit design can be cut into sections or stacked end to end
- Recessed screws and tubular contacts provide added safety and help prevent short circuits
- Tubular contacts connect stripped, un-terminated solid or stranded wire directly to each contact
- Integrated wire protectors prevent twisting and breakage of stranded wire during connection
- Rugged nylon construction rated to UL 94V2
- Ratings: Wire Range 22 - 10 AWG, 35A/300V UL Listed, CSA Certified.
Technical Information
Number of Poles: 12-Pole
Quantity: Individual
Length: 1,000'
Maximum Operating Temperature: 105°C
Maximum Rated Voltage: 300V
Maximum Wire Gauge: 10 AWG
Minimum Wire Gauge: 22 AWG
Torque (in / lb): 7
