IDEAL C6 Canadian Wiretwist Connectors Package of 100, Model 30-0C6

Description

The IDEAL Red Wiretwist Connectors are made in Canada. The C4 are good from 18 to 10 AWG (min. 2x18 AWG / max. 3x14 AWG)

Comes in a pack of 100 connectors.

Features

• Made in Canada
• Heavy gauge outer shell for superior dielectric performance
• Stay set spring with enhanced corrosion resistance
• No pre-twisting required
• CSA Certified (CSA 22.2 #188 Certified) and UL Listed for 600V maximum building wire and 1000V maximum for signage/fixture applications
• Wire combinations from 18 to 10 AWG (min. 2x16 + 2x18 / max. 3x10)
• Operating temperature up to 105 ºC / 221 ºF
• Flame-retardant shell

Technical Information

Twist-On Style: Non-Wing
Termination Method: Twist-On
Color: Red
Minimum Wire Gauge: 18 AWG
Maximum Wire Gauge: 10 AWG
Maximum Rated Voltage: 600V
Quantity: 100/pack
