IDEAL Thermo-Shrink 1"x4' Heavy-Wall Heat Shrink, Model 46-610*

Description

Ideal Industries Thin-Wall Thermo-Shrink heat shrinkable tubing. Roll of 4' long 1" diameter. Suitable for cable range 2/0 MCM - 500 MCM.

Benefits

• Polyolefin material electrically insulates and protects in-line components, disconnect terminals and splices with its high strength and excellent resilience
• Use to bundle wires for very flexible light-duty harnesses
• Highly flame-retardant and flexible; resistant to common fluids and solvents
• Meets UL 486D 125°C VW-1 600V; Material: No PBB’s, PBBE’s, conforms to ROHS
• 2:1 shrink ratio; Minimum shrink temperature: 70°C; Operating temperature: -55°C to +125°C
• RoHS compliant
• UV resistant

Technical Information

Normal Size: 1"
Expanded I.D. (Min.) 1.043"/26.5mm
Nominal Recovered I.D. (Max.): 0.500"/12.7mm
Recovered Wall Thickness +/- 10%: 0.031"/0.80mm
Max. Cable Range: 500 MCM
Min. Cable Range: 2/0 MCM
Heat Shrink Length: 4 ft.
Heat Shrink Type: Thin-Wall
