Intermatic Ivory Electronic Countdown Timer, Preset Times 5-10-15-30 Minutes with Hold, Model EI200*
Intermatic Ivory Electronic Countdown Timer, Preset Times 5-10-15-30 Minutes with Hold, Model EI200*
Description
This timer requires no programming; preset countdown times are activated by pressing a single button. Silent operation makes this timer ideal for applications where the noise of mechanical countdown timers is of concern. *NOTE: Not for use with sunlamps, saunas, or loads that could cause personal injury if timed incorrectly.
***Wallplate not included***
Features
- No programming required
- Provides silent operation in time ranges from five minutes to 30 minutes
- Single-button time selection, with some models having a HOLD mode, for continuous ON operation
- Replaces single-pole switches in a variety of applications
- Incandescent/fluorescent/CFL/LED compatible
- For use with decorator-style wall plate (not included)
- Requires neutral connection
Technical Information
Color: Ivory
Input Voltage Range: 120VAC - 60 Hz
Neutral Connection Required: Yes
Wiring Configurations: Single
Wall Plate Configurations: Single-Gang
Mechanism Type: Digital/Electrical
Operation Mode: Countdown
Hold Mode Included: Yes
Countdown Time: 30 Min
Time Presets: 5 min, 10 min, 15 min, 30 min
Application Compatibilities: CFL, Fluorescent, Incandescent, LED
Ballast Fluorescent: 8A, 1000VA
Electronic Ballast LED: 4A, 500VA
Motor Three Phase Ranges: 1/4 HP
Resistive Heater: 15A, 1800W
Tungsten Incandescent: 1000W
Operating Temperature Max: 104°F (40°C)
Operating Temperature Min: 32°F (0°C)
Product Depth: 1.438in (36.5mm)
Product Height: 4.125in (104.8mm)
Product Width: 1.6888in (42.93mm)
RoHS Certification: Yes
Country of Origin: China
Warranty Period: 1-Year Limited
Document
Original: $58.52
-65%$58.52
$20.48
Description
Description
This timer requires no programming; preset countdown times are activated by pressing a single button. Silent operation makes this timer ideal for applications where the noise of mechanical countdown timers is of concern. *NOTE: Not for use with sunlamps, saunas, or loads that could cause personal injury if timed incorrectly.
***Wallplate not included***
Features
- No programming required
- Provides silent operation in time ranges from five minutes to 30 minutes
- Single-button time selection, with some models having a HOLD mode, for continuous ON operation
- Replaces single-pole switches in a variety of applications
- Incandescent/fluorescent/CFL/LED compatible
- For use with decorator-style wall plate (not included)
- Requires neutral connection
Technical Information
Color: Ivory
Input Voltage Range: 120VAC - 60 Hz
Neutral Connection Required: Yes
Wiring Configurations: Single
Wall Plate Configurations: Single-Gang
Mechanism Type: Digital/Electrical
Operation Mode: Countdown
Hold Mode Included: Yes
Countdown Time: 30 Min
Time Presets: 5 min, 10 min, 15 min, 30 min
Application Compatibilities: CFL, Fluorescent, Incandescent, LED
Ballast Fluorescent: 8A, 1000VA
Electronic Ballast LED: 4A, 500VA
Motor Three Phase Ranges: 1/4 HP
Resistive Heater: 15A, 1800W
Tungsten Incandescent: 1000W
Operating Temperature Max: 104°F (40°C)
Operating Temperature Min: 32°F (0°C)
Product Depth: 1.438in (36.5mm)
Product Height: 4.125in (104.8mm)
Product Width: 1.6888in (42.93mm)
RoHS Certification: Yes
Country of Origin: China
Warranty Period: 1-Year Limited
