Klein Tools GFCI Receptacle Tester, Model RT210

Description

Klein Tools Receptacle Testers are designed to detect the most common wiring problems in standard and GFCI receptacles. A convenient chart on the tester helps determine wiring conditions in the outlet, based on LED lights results. Conditions indicated: open ground, reverse polarity, open hot, open neutral, hot/ground reversed.

Benefits

• Detects the most common wiring problems in standard and GFCI receptacles
• Works on GFI outlets and confirms operation of the ground fault protective device
• Conforms to UL Std 1436, Certified to CSA Std C22.2 #160
• Built to withstand a 6.6-foot (2m) drop
• Operating temp: 32-degrees F to 140-degrees F (0-degrees C to 40-degrees C)
• Nominal Voltage: 110/125V AC at 50/60Hz in 3-wire outlet

Technical Information

Type: GFCI and Standard Receptacle Tester
Application: Determine Wiring Condition in Outlet
Features: Convenient Chart on the Tester
Drop Protection: 6.6' (2 m)
GFCI: Yes
Voltage: 110/125V AC at 50/60Hz in. 3-Wire Outlet
Overall Length: 1.62'' (4.1 cm)
Overall Height: 2.88'' (7.3 cm)
Overall Width: 1.88'' (4.8 cm)
Weight: 1.9 oz (54 g)

Documents

GFCI Receptacle Tester Instruction Manual
