Liteline 2" Luna LED White Round Recessed Fixture, Dim to Warm, Model RA2-7F-DTW90WH*
Description
The RA2-7F is a 7 watt 2" round fixed recessed light fixture for retrofit application. It is a high-performance, easy to install downlight solution that offers good light output, energy-efficiency and streamlined design. Suitable for wet locations.
Features
- Durable airtight aluminum body with adjustable gimbal. Includes anodized blue heat sink to provide maximum airflow for the LED light source.
- This general application light fixture features a 7 watt LED module that maintains uniform intensity producing up to 450 lumens; with a typical CRI of 90.
- Color temperature dimming from 3000 K to 2000 K. This fixture is compatible with industry standard forward-phase / reverse-phase and TRIAC/ELV dimmers
- The fixture lens provides 40° beam spread.
- Includes two spring loaded clips to attached to any ceiling material
- Extruded aluminum hardwire box with 170mA dimmable class II electronic LED driver with 100-135V AC input. Includes an 18"FT6 rated cable with DC 2.1 connector between driver and fixture approved for use in plenums and suspended ceilings
- Three "Quick connect" push-in terminals for fast and easy wiring.
- Operating temperature range from -20°C to 40°C (-4°F to 104°F)
- Suitable for wet locations and suitable for insulated ceiling applications. Approved for direct contact with insulation. Airtight
Technical Information
Application: Ceiling Recess Mount
Approved Location: Wet / Insulated Ceilings
Beam Angle: 40°
CCT: 3000 K~2000 K
Certification: cETLus
Class II: Yes
Color: White
CRI: 90+
Dimming: Yes
Dimming Tech: Forward/reverse-phase - TRIAC/ELV
Hole Cut: Ø 2-1/2" (64mm)
Input: 100-135V AC, 60Hz
Lumens: 700
Lumens per Watt: 64
Power Factor: >0.90
Projected Life: 70% @ 33,000 hrs
Warranty: Lifetime
Wattage: 7W
Document
Specification Sheet
Original: $66.77
-65%$66.77
$23.37
