Liteline OnCloud Smart Wi-Fi 3-Way Switch, Model LC-CRTL-3WAY-1*
Description
The OnCloud Smart Wi-Fi 3-Way Switch works with any 120V bulb or fixture - every time. Works in 3-way or 4-way applications
Features
- Durable polycarbonate body with snap-on faceplate
- The smart Wi-Fi 3-way switch povides a maximum output of 1200W
- Certified IEEE 802.11 b/g Wi-Fi 2.4Ghz radio
- Installs into 3-way or 4-way switch applications (only one smart Wi-Fi switch can be installed in any 3-way application
- NEUTRAL WIRE REQUIRED
- The switch can be controlled via WiZ App (Works with iOS and Android from anywhere. Voice control can also be achieved by integrating the app with most smart speakers. Works with Google Assistant, Siri, Alexa and IFTTT
- Operating temperature from -5°C to 45°C (23°F to 113°F)
- Suitable for indoor dry location use only
Technical Information
Approved Location: Dry / Indoor
Input Voltage: 120 Vac - 60 Hz
Certification: cETLus
Output Current: Incandescent load: 10A; LED/CFL load: 5A
Power Consumption: OFF: 0.80W; ON: 1.28W
Rated Power: 1200W
Wireless Frequency: 2.4GHz
Wireless Standard: IEEE 802.11 b/g
Warranty: 3-Year
