Greenlee Industrial Clamp Meter, Model CMI-600*

Description

Allows you to speed through startups and troubleshoot a wide range of issues, including AC+DC current and voltage, along with a three-terminal phase sequence and motor rotation testing, eliminating the need for separate testers. The AmpTip feature increases accuracy on small wires and low current, along with peak-RMS for measurement of motor in rush current.

Benefits

• Speed through startups and troubleshoot a wide range of issues including AC+DC current and voltage
• Measures AC+DC current and DC microamps
• AC and AC+DC voltage measurements with digital filter low pass for accurate readings on variable frequency drives
• Also measures DC voltage, resistance, capacitance, temperature and frequency
• Tests continuity and diodes
• Three-terminal phase sequence and motor rotation testing. No need for separate testers
• Peak-RMS measures motor in rush current
• Backlight & relative mode for added versatility
• AmpTip increases accuracy on small wires and low current
• Two voltage detection modes - non-contact or using a single test lead
• Data hold
• Recording of Maximum, Minimum, and Average readings
• Compatible with a wide range of electrical equipment
• Includes: (1) Clamp Meter, (2) 1.5V AAA batteries, (1) Set of test leads and clips, (1) Carrying case

Technical Information

Brand: Greenlee
Amperage Measurement : 60, 600 Amps AC+DC
Display : LCD, 6000 Count
Frequency Rating : Voltage and AmpTip™ current: 50/60 Hz. High current: 50 to 400 Hz
Jaw Opening : 1.18" (30 mm)
Measurement Category : CAT III 600V, CAT IV 300V
Replacement Part : 02714 test leads and clips, TC-10 carrying case
Resistance Measurement : 600, 6k, 60k Ohms
Standard : CAT III, C/US UL Listed, CE
True Power : AC+DC True RMS
Voltage Measurement : 600 Volts AC+DC



Documents

Instruction Manual
