Klein Tools HVAC Digital Clamp Meter, 400 Amps, Model CL320

Description

Klein Tools CL320 is an automatically ranging true root mean square
(TRMS) digital clamp meter that measures AC current via the clamp,
AC/DC voltage, DC microamps, resistance, continuity, frequency,
capacitance, and tests diodes via test-leads, and temperature via a
thermocouple probe.

Benefits

• Clamp Meter with automatically ranging true mean squared (TRMS) technology for increased accuracy
• Measures AC current via the clamp and AC/DC voltage, DC microamps, resistance, continuity, frequency, capacitance and test diodes via the test leads
• Thermocouple probe measures temperature
• Built to withstand a 6.6-foot (2 m) drop
• CAT III 600V, Class 2, Double insulation safety rating
• Backlit display for clear readings
• Powers off automatically after 15 minutes of non-use to conserve battery life
• Includes a carrying case, test leads, and 3 x AAA batteries
• Low battery indicator and easily accessible battery compartment
• Meets requirements for use in basic and controlled electromagnetic environments like residential, office and light-industrial locations
• Included: Carrying Case, 41'' (1041.4 mm) Test Leads, Thermocouple with Adapter, and Batteries

Technical Information

Application: Measures AC Current, DC micro-Amp current
Functions: AC current, AC/DC voltage, DC micro-Amps, resistance, continuity, frequency, capacitance and test diodes.
Material: ABS
Batteries: 3 x AAA
Auto-Power Off: Yes
Jaw Size: 1.12'' (2.9 cm)
Drop Protection: 3.3' (1 m)
Display: 4000 Count LCD
Voltage: 600V AC; 600V DC
Frequency: 10Hz - 1 MHz
Current: 400A AC
Capacitance: 4000µF
Ohms (Resistance): 40MΩ
AC Voltage: 600
DC Voltage: 600
DC Polarity Indicator: Yes
DC Micro-Amp: 200 μA
Temperature Range: -40° to 1832°F (-40° to 1000°C)
Standard: CAT III 600V; CE Certified
Overall Length: 8.7'' (22.1 cm)
Overall Height: 1.61'' (4.1 cm)
Overall Width: 3.02'' (7.7 cm)
Weight: 10.1 oz (286 g)
